Electro-Voice RE20 at a Glance:
Electro Voice Re20 Serial Number Search
- Cardioid Mic
- Large-diaphragm Dynamic
- Immune to Proximity Effect
Cardioid Mic
A true cardioid microphone, the RE20 offers greatest rejection at 180 degree off-axis - directly to the rear of the microphone. Pattern control is so consistent that the frequency response is nearly independent of angular location of the sound source, creating virtually no off-axis coloration, yet providing the greatest possible rejection of unwanted sounds. An integral blast and wind filter covers each acoustic opening on the RE20. In recording sessions or on stage, singers can 'close talk' the microphone, singing with their lips almost touching the grille screen with no worry of 'P-pops' or excessive sibilance. Part of the filter also shock mounts the internal microphone element, reducing the transfer of vibrations from external sources.
Electro-Voice (EV) is an American manufacturer of audio equipment, including microphones, amplifiers, and loudspeakers, focused on pro audio applications such as sound reinforcement.As a subdivision of Telex Communications Inc. Since February 1998, Electro-Voice markets products for use by consumers as well as small or large concert venues, broadcasting, houses of. The Electro-Voice RE20 is a dynamic cardioid microphone so it is limited and you should know that. Like I said it was created specially for recording, broadcast and sometimes live for horns and kick. It does have a bass enhanced sound so be aware of that when you buy this mic but if you want a great mic for about 400.00 Ebay.
Large-diaphragm Dynamic
The exceptional performance of the RE20 is achieved by using a large Acoustalloy diaphragm in combination with an exceptionally low-mass aluminum voice coil. Using this diaphragm assembly, the RE20 is capable of reproducing extremely high sound pressure levels with no fear of the overload and distortion often experienced with phantom-powered condensers. The RE20 will also continue to function flawlessly in high humidity and elevated temperatures that would seriously degrade competitive condenser microphones. A massive steel housing and effective hum-bucking coil assure the RE20's resistance to magnetically induced hum and noise. This means the RE20 can be used successfully in situations where other microphones would experience unacceptable levels of hum and buzz. By exploiting the strength of its steel housing and employing a mechanical nesting concept, EV designers have created an exceptionally rugged microphone with superior handling noise rejection ideally suited for professional uses.
Immune to Proximity Effect
The bass-boosting proximity effect common to most directional microphones when used close to the sound source, is eliminated in the RE20. This is accomplished via the application of the EV-exclusive Variable-D technology. By controlling the effect of microphone proximity, the RE20 can be located very close to sound sources without a loss in clarity or definition making the RE20 ideal for tight vocals and challenging instruments. It can be used inside bass drums, on acoustic guitars, and is found in voice booths and broadcasting studios everywhere.
Electro Voice Re20 Serial Number Lookup
- Generating Element: Dynamic
- Frequency Response: 45Hz-18kHz
- Polar Pattern: Cardioid
- Virtually free of proximity effect
- Impedance: 150 ohms balanced
- Sensitivity, Open Circuit
- Polarity: Pin 2 will be positive referenced to Pin
- 3 with positive pressure on diaphragm
- Case Material: Steel
- Accessories Furnished: 81715 stand clamp
